PLC Based Rapid Jet Dyeing Machine

Machine pressure vessel and major wet parts are fabricated out of stainless steel AISI 316/316L highly corrosion resistant material.

Heavy duty stainless steel centrifugal pump for optional dye liquor circulation.

Highly efficient heat exchanger for fast heating and cooling.

One stainless steel filtering device placed in such a way for easy cleaning. One unique design of jet nozzle can provide high discharge of liquor with subsequent pressure to ensure fast movement of fabric transport upto 300 Mtrs/min and the speed of fabric can be adjusted, required to desired quality.

A mirror polished fabric transport perforated basket for easy trouble free movement of fabric from back to the front of machine. The perforated basket fabricated in such a way that the welded part does not come in contact with the fabric.

For preparing chemical, color kitchen tank is made out of stainless steel 316, and is provided with required values for auto dozing.

All valves are made of investment casting and stainless steel 316.

Electrical control panel with microprocessors to operate the machine is provided with pneumatic control circuits.

Magnetic level indicator duly calibrated for correct liquor measurement.

Take off reel with direct couple geared motor and stainless steel structure.

All safety device required for a pressure vessel is incorporated with the machine.

Product Details :

• Feed pump to colour Kitchen Tank.
• Seam Detector.
• Fully automatic device with PLC and Pneumatic Operated
• Control Values.
